Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.709" Dia (18.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 105°C
• Applications General Purpose
• Lead Spacing 0.295" (7.50mm)
• Lifetime @ Temp. 8000 Hrs @ 105°C
• Height - Seated (Max) 0.846" (21.50mm)
• Capacitance 5.6 mF
• Voltage - Rated 10 V
• Ripple Current @ Low Frequency 2.431 A @ 120 Hz
• Ripple Current @ High Frequency 2.86 A @ 100 kHz
