Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.630" Dia (16.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 125°C
• Applications General Purpose
• Lead Spacing 0.295" (7.50mm)
• Lifetime @ Temp. 5000 Hrs @ 125°C
• Height - Seated (Max) 1.260" (32.00mm)
• Capacitance 330 µF
• Voltage - Rated 100 V
• Ripple Current @ Low Frequency 910 mA @ 120 Hz
• Ripple Current @ High Frequency 1.3 A @ 100 kHz
