Technical Details

• Tolerance -10%, +30%
• Package / Case Axial, Can
• Size / Dimension 0.394" Dia x 1.142" L (10.00mm x 29.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 125°C
• Applications General Purpose
• ESR (Equivalent Series Resistance) 1.2Ohm @ 100Hz
• Lifetime @ Temp. 2000 Hrs @ 125°C
• Capacitance 100 µF
• Voltage - Rated 25 V
• Ripple Current @ Low Frequency 255 mA @ 100 Hz
• Ripple Current @ High Frequency 1.5 A @ 5 kHz
