Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.630" Dia (16.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 125°C
• Applications Automotive
• Lead Spacing 0.295" (7.50mm)
• Ratings AEC-Q200
• Lifetime @ Temp. 5000 Hrs @ 125°C
• Height - Seated (Max) 1.063" (27.00mm)
• Capacitance 560 µF
• Voltage - Rated 63 V
• Impedance 48 mOhms
• Ripple Current @ Low Frequency 900 mA @ 100 Hz
• Ripple Current @ High Frequency 1.8 A @ 100 kHz
