Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.315" Dia (8.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -25°C ~ 105°C
• Applications General Purpose
• Lead Spacing 0.138" (3.50mm)
• Lifetime @ Temp. 1000 Hrs @ 105°C
• Height - Seated (Max) 0.433" (11.00mm)
• Capacitance 1 µF
• Voltage - Rated 450 V
