Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Screw Terminals
• Size / Dimension 3.028" Dia (76.90mm)
• Polarization Polar
• Mounting Type Chassis Mount
• Operating Temperature -25°C ~ 85°C
• Applications General Purpose
• Lead Spacing 1.248" (31.70mm)
• ESR (Equivalent Series Resistance) 17mOhm @ 100Hz
• Lifetime @ Temp. 12000 Hrs @ 85°C
• Height - Seated (Max) 4.693" (119.20mm)
• Capacitance 6800 µF
• Voltage - Rated 400 V
• Impedance 28 mOhms
• Ripple Current @ Low Frequency 18.4 A @ 100 Hz
