Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.630" Dia (16.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 125°C
• Applications Automotive
• Lead Spacing 0.295" (7.50mm)
• Ratings AEC-Q200
• ESR (Equivalent Series Resistance) 30mOhm @ 10kHz
• Lifetime @ Temp. 7000 Hrs @ 125°C
• Height - Seated (Max) 1.063" (27.00mm)
• Capacitance 1000 µF
• Voltage - Rated 35 V
• Impedance 26 mOhms
• Ripple Current @ High Frequency 2.86 A @ 100 kHz
