Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Screw Terminals
• Size / Dimension 2.031" Dia (51.60mm)
• Polarization Polar
• Mounting Type Chassis Mount
• Operating Temperature -25°C ~ 85°C
• Applications General Purpose
• Lead Spacing 0.874" (22.20mm)
• ESR (Equivalent Series Resistance) 80mOhm @ 100Hz
• Lifetime @ Temp. 5000 Hrs @ 85°C
• Height - Seated (Max) 3.217" (81.70mm)
• Capacitance 1500 µF
• Voltage - Rated 400 V
• Impedance 130 mOhms
• Ripple Current @ Low Frequency 6.59 A @ 100 Hz
