Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Snap-In
• Size / Dimension 0.984" Dia (25.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 105°C
• Applications General Purpose
• Lead Spacing 0.394" (10.00mm)
• ESR (Equivalent Series Resistance) 110mOhm @ 100Hz
• Lifetime @ Temp. 2000 Hrs @ 105°C
• Height - Seated (Max) 1.457" (37.00mm)
• Capacitance 820 µF
• Voltage - Rated 200 V
• Impedance 170 mOhms
• Ripple Current @ Low Frequency 1.85 A @ 100 Hz
