Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Snap-In - 3 Lead
• Size / Dimension 1.378" Dia (35.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -25°C ~ 85°C
• Applications General Purpose
• Lead Spacing 0.394" (10.00mm)
• ESR (Equivalent Series Resistance) 170mOhm @ 100Hz
• Lifetime @ Temp. 8000 Hrs @ 85°C
• Height - Seated (Max) 2.047" (52.00mm)
• Capacitance 680 µF
• Voltage - Rated 450 V
• Impedance 260 mOhms
• Ripple Current @ Low Frequency 3.48 A @ 100 Hz
