Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Screw Terminals
• Size / Dimension 2.031" Dia (51.60mm)
• Polarization Polar
• Mounting Type Chassis Mount
• Operating Temperature -40°C ~ 85°C
• Applications General Purpose
• Lead Spacing 0.874" (22.20mm)
• ESR (Equivalent Series Resistance) 26mOhm @ 100Hz
• Lifetime @ Temp. 12000 Hrs @ 85°C
• Height - Seated (Max) 4.693" (119.20mm)
• Capacitance 2700 µF
• Voltage - Rated 400 V
• Impedance 36 mOhms
• Ripple Current @ Low Frequency 13.2 A @ 100 Hz
