Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Screw Terminals
• Size / Dimension 3.543" Dia (90.00mm)
• Polarization Polar
• Mounting Type Chassis Mount
• Operating Temperature -25°C ~ 85°C
• Applications General Purpose
• Lead Spacing 1.248" (31.70mm)
• ESR (Equivalent Series Resistance) 5.2mOhm @ 100Hz
• Lifetime @ Temp. 15000 Hrs @ 85°C
• Height - Seated (Max) 8.740" (222.00mm)
• Capacitance 33000 µF
• Voltage - Rated 200 V
• Impedance 9.8 mOhms
• Ripple Current @ Low Frequency 45.9 A @ 100 Hz
