Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Screw Terminals
• Size / Dimension 2.531" Dia (64.30mm)
• Polarization Polar
• Mounting Type Chassis Mount
• Operating Temperature -40°C ~ 105°C
• Applications General Purpose
• Lead Spacing 1.122" (28.50mm)
• ESR (Equivalent Series Resistance) 18mOhm @ 100Hz
• Lifetime @ Temp. 5000 Hrs @ 105°C
• Height - Seated (Max) 5.185" (131.70mm)
• Capacitance 4700 µF
• Voltage - Rated 350 V
• Impedance 28 mOhms
• Ripple Current @ Low Frequency 12.5 A @ 100 Hz
