Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Snap-In
• Size / Dimension 1.181" Dia (30.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 105°C
• Applications General Purpose
• Lead Spacing 0.394" (10.00mm)
• ESR (Equivalent Series Resistance) 400mOhm @ 100Hz
• Lifetime @ Temp. 2000 Hrs @ 105°C
• Height - Seated (Max) 1.260" (32.00mm)
• Capacitance 270 µF
• Voltage - Rated 450 V
• Impedance 600 mOhms
• Ripple Current @ Low Frequency 1.18 A @ 100 Hz
