Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Snap-In
• Size / Dimension 0.866" Dia (22.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -25°C ~ 85°C
• Applications General Purpose
• Lead Spacing 0.394" (10.00mm)
• ESR (Equivalent Series Resistance) 490mOhm @ 100Hz
• Lifetime @ Temp. 8000 Hrs @ 85°C
• Height - Seated (Max) 1.654" (42.00mm)
• Capacitance 220 µF
• Voltage - Rated 400 V
• Impedance 740 mOhms
• Ripple Current @ Low Frequency 1.52 A @ 100 Hz
