Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.394" Dia (10.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 105°C
• Applications Automotive
• Lead Spacing 0.197" (5.00mm)
• Ratings AEC-Q200
• ESR (Equivalent Series Resistance) 461mOhm @ 10kHz
• Lifetime @ Temp. 5000 Hrs @ 105°C
• Height - Seated (Max) 0.866" (22.00mm)
• Capacitance 47 µF
• Voltage - Rated 100 V
• Impedance 423 mOhms
• Ripple Current @ High Frequency 460 mA @ 100 kHz
