Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.315" Dia (8.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 125°C
• Applications Automotive
• Lead Spacing 0.138" (3.50mm)
• Ratings AEC-Q200
• ESR (Equivalent Series Resistance) 646mOhm @ 100kHz
• Lifetime @ Temp. 2000 Hrs @ 125°C
• Height - Seated (Max) 0.512" (13.00mm)
• Capacitance 100 µF
• Voltage - Rated 35 V
• Impedance 573 mOhms
• Ripple Current @ High Frequency 297 mA @ 100 kHz
