Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - SMD
• Size / Dimension 0.197" Dia (5.00mm)
• Polarization Polar
• Mounting Type Surface Mount
• Operating Temperature -55°C ~ 105°C
• Applications General Purpose
• Surface Mount Land Size 0.209" L x 0.209" W (5.30mm x 5.30mm)
• Height - Seated (Max) 0.217" (5.50mm)
• Capacitance 4.7 µF
• Voltage - Rated 63 V
• Impedance 3 Ohms
• Ripple Current @ Low Frequency 29.5 mA @ 120 Hz
• Ripple Current @ High Frequency 50 mA @ 100 kHz
