Technical Details

• Tolerance ±20%
• Package / Case Axial, Can
• Size / Dimension 0.394" Dia x 1.024" L (10.00mm x 26.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 85°C
• Applications General Purpose
• Lifetime @ Temp. 2000 Hrs @ 85°C
• Capacitance 470 µF
• Voltage - Rated 35 V
• Ripple Current @ Low Frequency 610 mA @ 120 Hz
• Ripple Current @ High Frequency 915 mA @ 10 kHz
