Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.709" Dia (18.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 105°C
• Applications General Purpose
• Lead Spacing 0.295" (7.50mm)
• Lifetime @ Temp. 5000 Hrs @ 105°C
• Height - Seated (Max) 1.654" (42.00mm)
• Capacitance 150 µF
• Voltage - Rated 450 V
• Ripple Current @ Low Frequency 970 mA @ 120 Hz
• Ripple Current @ High Frequency 1.455 A @ 10 kHz
