Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.394" Dia (10.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 105°C
• Applications General Purpose
• Lead Spacing 0.197" (5.00mm)
• Lifetime @ Temp. 12000 Hrs @ 105°C
• Height - Seated (Max) 1.673" (42.50mm)
• Capacitance 150 µF
• Voltage - Rated 160 V
• Ripple Current @ Low Frequency 670 mA @ 120 Hz
• Ripple Current @ High Frequency 938 mA @ 100 kHz
