Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.394" Dia (10.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 105°C
• Applications General Purpose
• Lead Spacing 0.197" (5.00mm)
• Lifetime @ Temp. 12000 Hrs @ 105°C
• Height - Seated (Max) 2.067" (52.50mm)
• Capacitance 39 µF
• Voltage - Rated 450 V
• Ripple Current @ Low Frequency 410 mA @ 120 Hz
• Ripple Current @ High Frequency 615 mA @ 100 kHz
