Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - Snap-In - 3 Lead
• Size / Dimension 0.984" Dia (25.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 125°C
• Applications Automotive
• Lead Spacing 0.394" (10.00mm)
• ESR (Equivalent Series Resistance) 21mOhm @ 100Hz
• Lifetime @ Temp. 5000 Hrs @ 125°C
• Height - Seated (Max) 1.654" (42.00mm)
• Capacitance 5100 µF
• Voltage - Rated 40 V
• Ripple Current @ High Frequency 7.1 A @ 10 kHz
