Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 1.378" Dia (35.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 125°C
• Applications Automotive
• Lead Spacing 0.331" (8.40mm)
• ESR (Equivalent Series Resistance) 13mOhm @ 100Hz
• Lifetime @ Temp. 5000 Hrs @ 125°C
• Height - Seated (Max) 2.047" (52.00mm)
• Capacitance 8100 µF
• Voltage - Rated 63 V
• Ripple Current @ High Frequency 10 A @ 10 kHz
