Technical Details

• Tolerance ±20%
• Package / Case Radial, Can - SMD
• Size / Dimension 0.709" Dia (18.00mm)
• Polarization Polar
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 105°C
• Applications Automotive
• Ratings AEC-Q200
• Lifetime @ Temp. 6000 Hrs @ 105°C
• Surface Mount Land Size 0.748" L x 0.748" W (19.00mm x 19.00mm)
• Height - Seated (Max) 0.866" (22.00mm)
• Capacitance 33 µF
• Voltage - Rated 400 V
• Impedance 1.1 Ohms
• Ripple Current @ Low Frequency 190 mA @ 100 Hz
• Ripple Current @ High Frequency 475 mA @ 30 kHz
