Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.866" Dia (22.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 85°C
• Applications General Purpose
• Lead Spacing 0.394" (10.00mm)
• Lifetime @ Temp. 2000 Hrs @ 85°C
• Height - Seated (Max) 1.260" (32.00mm)
• Capacitance 3300 µF
• Voltage - Rated 50 V
• Ripple Current @ Low Frequency 2.45 A @ 120 Hz
• Ripple Current @ High Frequency 2.8175 A @ 10 kHz
