Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.197" Dia (5.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 105°C
• Applications General Purpose
• Lead Spacing 0.197" (5.00mm)
• Lifetime @ Temp. 1000 Hrs @ 105°C
• Height - Seated (Max) 0.472" (12.00mm)
• Capacitance 4.7 µF
• Voltage - Rated 50 V
• Ripple Current @ Low Frequency 45 mA @ 120 Hz
• Ripple Current @ High Frequency 90 mA @ 10 kHz
