Technical Details

• Tolerance ±20%
• Package / Case Radial, Can
• Size / Dimension 0.630" Dia (16.00mm)
• Polarization Polar
• Mounting Type Through Hole
• Operating Temperature -40°C ~ 85°C
• Applications General Purpose
• Lead Spacing 0.295" (7.50mm)
• Lifetime @ Temp. 2000 Hrs @ 85°C
• Height - Seated (Max) 1.063" (27.00mm)
• Capacitance 1000 µF
• Voltage - Rated 63 V
• Ripple Current @ Low Frequency 1.3 A @ 120 Hz
• Ripple Current @ High Frequency 1.495 A @ 10 kHz
